GMP Standard pharmaceutical Peeler Centrifugal Equipment Wall Through Type

Brief introduction

PPCC series horizontal wall-through full-automatic scraper discharge centrifuge is a continuous operation, gap operation filter centrifuge. The structure and system design fully consider the requirements of cGMP, TGA, and are suitable for clean requirements of pharmaceuticals, food, etc. High occasions, and can meet different explosion-proof requirements.

The PPCC type centrifuge is a fully open outer casing and wall-mounted installation type to ensure complete isolation of the work area and the power area to avoid pollution to the product. An independent hydraulic and lubrication system is equipped with a nitrogen protection system and a CIP online cleaning system. Using PLC program control, frequency conversion speed regulation, energy consumption braking system. The control method adopts full automatic control (can also be manually operated). The feeding, separation, washing, dehydration, discharge and filter cloth regeneration, online cleaning, nitrogen protection and other processes during the operation of the centrifuge are set in advance according to customer requirements The program runs.

Properties and Uses

PPCC automatic centrifuge is a solid-liquid separation equipment which adopts continuous operation and intermittent discharging.

The machine is controlled by PLC.It regulates speed by frequency convertor;braking system adopts dynamic braking and regenerative braking.Through such procedures as product level detection,speed inspection process is automatic circulative work(including feeding,dehydration,washing,discharging and etc.)Also manual operation mode is available which can be changed over from full-automation mode by customer’s will.

PPCC automatic centrifuge adopts wall penetration installation,its power area and processing area can be separated.It can be used in pharmaceutical industry which has high requirements.The whole housing bucket can be open for inspection and cleaning.

Technical parameters

Model	Drum diameter (mm)	Drum volume (L)	Loading capacity (kg)
PPCC-53	600	41	53
PPCC-130	800	100	130
PPCC-230	1000	180	230
PPCC-270	1050	210	270
PPCC-430	1250	335	430
PPCC-585	1350	450	585
PPCC-900	1600	700	900

Features
1.It is fully conformed to GMP, CGMP, and meet the requirements of sterile raw medicine production.
2.With absolute isolation between power area and process area. It is suitable for occasion when customer requires high quality cleaning to avoid the contamination to product.
3.The out shell bucket can be opened, so the whole internal parts could be observed and easy for touch wiping and cleaning.
4.Perfect CIP system can be carried out to wash the internal parts of centrifuge to avoid cross contamination which are not easy to clean.
5.Unique pneumatic counter-pulse device is equipped, which can remove remnant filter cake as much as possible.
6.Totally-enclosed structure equipped with inert gas protection is adopted to be used in ex-proof I section.
7.The automatic residual cakes removing device is optional (have owned the national patent).

Flow chart
