Jiangsu Hanpu Mechanical Technology Co., Ltd
5 Years
| Ask Lasest Price | |
| Brand Name : | Hanpu |
| Model Number : | MVR |
| Certification : | CE ISO |
| Price : | USD180,000-USD650,000 |
| Supply Ability : | 1sets per 3 months |
| Delivery Time : | 120days |
Food- and chemical-grade SS316L NaCl evaporation & crystallization line engineered for refined sodium chloride. The system integrates brine purification with vacuum evaporation (MEE and/or MVR) and controlled crystallization to deliver consistent grain size, high purity, and low moisture—ready for centrifuging, drying, sizing, iodization, and packing.
Clarified/polished brine is concentrated under vacuum using multi-effect and/or MVR duty. Tight control of ΔT/LMTD, circulation rate, and residence time stabilizes supersaturation, ensuring repeatable crystallization and low energy consumption.
Wetted parts in SS316L (duplex/Ti on request). Sanitary finishes, traceable materials, drainable piping, and validated CIP supporting HACCP/ISO programs for edible salt production.
| Parameter | Typical Target / Range* |
|---|---|
| NaCl purity (dry) | ≥ 99.2% (up to 99.7% with enhanced purification) |
| Final moisture | ≤ 0.2% (grade-dependent) |
| Crystal sizes | Fine 0.2–0.5 mm; Table 0.5–1.2 mm; Coarse 1.2–2.5 mm |
| Line capacity | 5–500 t/day (modular trains) |
| Energy use (MVR) | ~15–40 kWh per ton H₂O evaporated |
| Fresh steam demand | Very low after start-up (with MVR) |
| Campaign length | ≥ 10–20 days between CIP (feed-dependent) |
*Performance depends on feed composition, scaling tendency, compression ratio, and heat-transfer area.
Yes. We tune nucleation/growth and add post-sieving/polishing to supply fine, table, or coarse grades.
Material traceability, surface-finish records, and CIP validation are provided to support HACCP/ISO 22000.
Through multi-effect staging and optional MVR, plus heat recovery and optimized ΔT/LMTD and circulation.
|
|
